دیتاشیت TN1515-600B-TR
مشخصات دیتاشیت
| نام دیتاشیت |
TN1515-600B
|
| حجم فایل |
201.578
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/TRIACs
-
SCR Type:
One-way thyristor
-
Datasheet:
STMicroelectronics TN1515-600B-TR
-
Holding Current (Ih):
40mA
-
Operating Temperature:
-40°C~+125°C
-
Gate Trigger Current(Igt):
15mA
-
Gate Trigger Voltage (Vgt):
1.3V
-
RMS On-State Current(It (rms)):
15A
-
Peak Forward On?State Voltage (Vtm):
1.6V
-
Peak Repetitive Off?State Voltage (Vdrm):
600V
-
Package:
TO-252-2(DPAK)
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Off State:
600V
-
Voltage - Gate Trigger (Vgt) (Max):
1.3V
-
Current - Gate Trigger (Igt) (Max):
15mA
-
Voltage - On State (Vtm) (Max):
1.6V
-
Current - On State (It (AV)) (Max):
9.5A
-
Current - On State (It (RMS)) (Max):
15A
-
Current - Hold (Ih) (Max):
40mA
-
Current - Off State (Max):
5µA
-
Current - Non Rep. Surge 50, 60Hz (Itsm):
150A, 165A
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Supplier Device Package:
DPAK
-
Base Part Number:
TN1515
-
detail:
SCR 600V 15A Standard Recovery Surface Mount DPAK
