TN1515-600B-TR
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | STMicroelectronics |
| Package | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Datasheet | TN1515-600B |
| Description | SCR 600V 15A Standard Recovery Surface Mount DPAK |
فروشنده های TN1515-600B-TR
فروشگاهی یافت نشد
مشخصات TN1515-600B-TR
- RoHS true
- Category Triode/MOS Tube/Transistor/TRIACs
- SCR Type One-way thyristor
- Datasheet STMicroelectronics TN1515-600B-TR
- Holding Current (Ih) 40mA
- Operating Temperature -40°C~+125°C
- Gate Trigger Current(Igt) 15mA
- Gate Trigger Voltage (Vgt) 1.3V
- RMS On-State Current(It (rms)) 15A
- Peak Forward On?State Voltage (Vtm) 1.6V
- Peak Repetitive Off?State Voltage (Vdrm) 600V
- Package TO-252-2(DPAK)
- Manufacturer STMicroelectronics
- Series -
- Packaging Cut Tape (CT)
- Part Status Active
- Voltage - Off State 600V
- Voltage - Gate Trigger (Vgt) (Max) 1.3V
- Current - Gate Trigger (Igt) (Max) 15mA
- Voltage - On State (Vtm) (Max) 1.6V
- Current - On State (It (AV)) (Max) 9.5A
- Current - On State (It (RMS)) (Max) 15A
- Current - Hold (Ih) (Max) 40mA
- Current - Off State (Max) 5µA
- Current - Non Rep. Surge 50, 60Hz (Itsm) 150A, 165A
- Mounting Type Surface Mount
- Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package DPAK
- Base Part Number TN1515
- detail SCR 600V 15A Standard Recovery Surface Mount DPAK
