دیتاشیت SN74LS08NSR

SN54,74(LS,S)08

مشخصات دیتاشیت

نام دیتاشیت SN54,74(LS,S)08
حجم فایل 1341.763 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت SN54,74(LS,S)08

SN54,74(LS,S)08 Datasheet

مشخصات

  • RoHS: true
  • Series: 74LS
  • Category: Logic ICs/Gates
  • Datasheet: Texas Instruments SN74LS08NSR
  • Sink Current: 8mA
  • Source Current: 400uA
  • Supply Voltage: 4.75V~5.25V
  • Logic Gate Type: And
  • Number of Channels: 4
  • Low Level Range (VIL): 0.8V
  • Operating Temperature: 0°C~+70°C
  • High Level Range (VIH): 2V
  • Propagation Delay Time: 20ns@5V,15pF
  • Package: SOP-14-208mil
  • Manufacturer: Texas Instruments
  • Logic Level - High: 2V
  • Base Part Number: SN74LS08
  • Supplier Device Package: 14-SOP
  • Logic Level - Low: 0.8V
  • Package / Case: 14-SOIC (0.209", 5.30mm Width)
  • Current - Output High, Low: 400µA, 8mA
  • Features: -
  • Mounting Type: Surface Mount
  • Packaging: Cut Tape (CT)
  • Voltage - Supply: 4.75V ~ 5.25V
  • Number of Circuits: 4
  • Max Propagation Delay @ V, Max CL: 20ns @ 5V, 15pF
  • Number of Inputs: 2
  • Part Status: Active
  • Logic Type: AND Gate
  • detail: AND Gate IC 4 Channel 14-SOP
