STFI26NM60N دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STFI26NM60N
|
|
حجم فایل
|
60.708
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
STMicroelectronics STFI26NM60N
-
Power Dissipation (Pd):
35W
-
Drain Source Voltage (Vdss):
600V
-
Continuous Drain Current (Id):
20A
-
Gate Threshold Voltage (Vgs(th)@Id):
4V@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
165mΩ@10V,10A
-
Package:
TO-281
-
Manufacturer:
STMicroelectronics
-
Series:
MDmesh™ II
-
Packaging:
Tube
-
Part Status:
Obsolete
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
600V
-
Current - Continuous Drain (Id) @ 25°C:
20A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
165mOhm @ 10A, 10V
-
Vgs(th) (Max) @ Id:
4V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
60nC @ 10V
-
Vgs (Max):
±25V
-
Input Capacitance (Ciss) (Max) @ Vds:
1800pF @ 50V
-
FET Feature:
-
-
Power Dissipation (Max):
35W (Tc)
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
I2PAKFP (TO-281)
-
Package / Case:
TO-262-3 Full Pack, I²Pak
-
Base Part Number:
STFI26N
-
detail:
N-Channel 600V 20A (Tc) 35W (Tc) Through Hole I2PAKFP (TO-281)
