دیتاشیت ADG5412BRUZ-REEL7
مشخصات دیتاشیت
| نام دیتاشیت | ADG5412/13 |
|---|---|
| حجم فایل | 468.786 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 19 |
دانلود دیتاشیت ADG5412/13 |
ADG5412/13 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices ADG5412BRUZ-REEL7
- Turn-on time: 187ns
- Turn-off time: 138ns
- Supply Voltage: 9V~40V
- Switch Circuit: SPST(SPST)-Normal Open
- Number of Channels: 4
- On-State Resistance (Max): 10Ω
- Package: TSSOP-16
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Multiplexer/Demultiplexer Circuit: 1:1
- Number of Circuits: 4
- Channel-to-Channel Matching (ΔRon): 350mOhm
- Voltage - Supply, Single (V+): 9V ~ 40V
- Voltage - Supply, Dual (V±): ±9V ~ 22V
- Switch Time (Ton, Toff) (Max): 187ns, 138ns
- -3db Bandwidth: 160MHz
- Charge Injection: 310pC
- Channel Capacitance (CS(off), CD(off)): 17pF, 17pF
- Current - Leakage (IS(off)) (Max): 250pA
- Crosstalk: -70dB @ 1MHz
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 16-TSSOP
- Base Part Number: ADG5412
- detail: 4 Circuit IC Switch 1:1 10Ohm 16-TSSOP
