دیتاشیت ADG734BRUZ-REEL
مشخصات دیتاشیت
| نام دیتاشیت | ADG734BRUZ-REEL |
|---|---|
| حجم فایل | 83.957 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
ADG734BRUZ-REEL |
دانلود دیتاشیت |
|---|
سایر مستندات
20-TSSOP Pkg Drawing 1 pages
ADG733,734 12 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices ADG734BRUZ-REEL
- Turn-on time: 21ns
- Turn-off time: 10ns
- Supply Voltage: 1.8V~5.5V
- Switch Circuit: SPDT(SPDT)
- Number of Channels: 4
- On-State Resistance (Max): 4.5Ω
- Package: TSSOP-20
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 4
- Channel-to-Channel Matching (ΔRon): -
- Voltage - Supply, Single (V+): 1.8V ~ 5.5V
- Voltage - Supply, Dual (V±): ±2.5V
- Switch Time (Ton, Toff) (Max): 21ns, 10ns (Typ)
- -3db Bandwidth: 200MHz
- Charge Injection: 5pC
- Channel Capacitance (CS(off), CD(off)): 11pF
- Current - Leakage (IS(off)) (Max): 100pA
- Crosstalk: -67dB @ 1MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 20-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 20-TSSOP
- Base Part Number: ADG734
- detail: 4 Circuit IC Switch 2:1 4.5Ohm 20-TSSOP
