دیتاشیت PIC16F1847-I/MV
مشخصات دیتاشیت
| نام دیتاشیت |
PIC16(L)F1847
|
| حجم فایل |
4469.922
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
418
|
مشخصات
-
RoHS:
true
-
EEPROM:
8KB
-
CPU Core:
PIC
-
Category:
Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
-
RAM Size:
1KB
-
Watchdog:
Yes
-
ADC (Bit):
10bit
-
DAC (Bit):
-
-
Datasheet:
Microchip Tech PIC16F1847-I/MV
-
PWM (Bit):
-
-
Real-Time Clock:
-
-
CPU Maximum Speed:
32MHz
-
GPIO Ports Number:
15
-
Low-Voltage Detect:
Yes
-
CCP Capture/Compare:
-
-
Internal Comparator:
-
-
Internal Oscillator:
Yes
-
Peripheral/Function:
PWM
-
Program Memory Type:
FLASH
-
Direct Memory Access:
-
-
Program Storage Size:
16KB
-
Universal Serial Bus:
-
-
communication protocol:
-
-
Operating Voltage Range:
1.8V~5.5V
-
Infrared Data Association:
-
-
Operating Temperature Range:
-40°C~+85°C
-
Secure Digital Input and Output:
-
-
Package:
QFN-28-EP(4x4)
-
Manufacturer:
Microchip Tech
-
Series:
PIC® XLP™ mTouch™ 16F
-
Packaging:
Tube
-
Part Status:
Active
-
Core Processor:
PIC
-
Core Size:
8-Bit
-
Speed:
32MHz
-
Connectivity:
I²C, LINbus, SPI, UART/USART
-
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
-
Number of I/O:
15
-
Program Memory Size:
14KB (8K x 14)
-
EEPROM Size:
256 x 8
-
Voltage - Supply (Vcc/Vdd):
1.8V ~ 5.5V
-
Data Converters:
A/D 12x10b
-
Oscillator Type:
Internal
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
28-UFQFN Exposed Pad
-
Supplier Device Package:
28-UQFN (4x4)
-
Base Part Number:
PIC16F1847
-
detail:
PIC PIC® XLP™ mTouch™ 16F Microcontroller IC 8-Bit 32MHz 14KB (8K x 14) FLASH 28-UQFN (4x4)
