دیتاشیت ADG839YKSZ-500RL7

مشخصات دیتاشیت

دانلود دیتاشیت ADG839	ADG839 Datasheet

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADG839YKSZ-500RL7
Turn-on time: 16ns
Turn-off time: 8.5ns
Supply Voltage: 1.65V~3.6V
Switch Circuit: SPDT(SPDT)
Number of Channels: 1
On-State Resistance (Max): 500mΩ
Package: SC-70-6
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Multiplexer/Demultiplexer Circuit: 2:1
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): 40mOhm
Voltage - Supply, Single (V+): 1.65V ~ 3.6V
Voltage - Supply, Dual (V±): -
Switch Time (Ton, Toff) (Max): 16ns, 8.5ns
-3db Bandwidth: 25MHz
Charge Injection: 70pC
Channel Capacitance (CS(off), CD(off)): 74pF
Current - Leakage (IS(off)) (Max): 200pA (Typ)
Crosstalk: -57dB @ 100kHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 6-TSSOP, SC-88, SOT-363
Supplier Device Package: SC-70-6
Base Part Number: ADG839
detail: 1 Circuit IC Switch 2:1 500mOhm SC-70-6
