دیتاشیت PIC18F4321-E/PT
مشخصات دیتاشیت
| نام دیتاشیت | PIC18F(2, 4)zzz Programming Specification |
|---|---|
| حجم فایل | 393.767 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 56 |
دانلود دیتاشیت PIC18F(2, 4)zzz Programming Specification |
PIC18F(2, 4)zzz Programming Specification Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: 256Byte
- CPU Core: PIC
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: Yes
- ADC (Bit): 10bit
- DAC (Bit): -
- Datasheet: Microchip Tech PIC18F4321-E/PT
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 25MHz
- GPIO Ports Number: 36
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 8KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 4.2V~5.5V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+125°C
- Secure Digital Input and Output: -
- Package: TQFP-44(10x10)
- Manufacturer: Microchip Tech
- Series: PIC® 18F
- Packaging: Tray
- Part Status: Active
- Core Processor: PIC
- Core Size: 8-Bit
- Speed: 25MHz
- Connectivity: I²C, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, HLVD, POR, PWM, WDT
- Number of I/O: 36
- Program Memory Size: 8KB (4K x 16)
- EEPROM Size: 256 x 8
- Voltage - Supply (Vcc/Vdd): 4.2V ~ 5.5V
- Data Converters: A/D 13x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 44-TQFP
- Supplier Device Package: 44-TQFP (10x10)
- Base Part Number: PIC18F4321
- detail: PIC PIC® 18F Microcontroller IC 8-Bit 25MHz 8KB (4K x 16) FLASH 44-TQFP (10x10)
