دیتاشیت ADG1434YRUZ-REEL7

ADG1433,34

مشخصات دیتاشیت

نام دیتاشیت ADG1433,34
حجم فایل 394.018 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت ADG1433,34

ADG1433,34 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Circuit: SPDT
  • Multiplexer/Demultiplexer Circuit: 2:1
  • Number of Circuits: 4
  • On-State Resistance (Max): 4.7Ohm
  • Channel-to-Channel Matching (ΔRon): 500mOhm
  • Voltage - Supply, Single (V+): 5V ~ 16.5V
  • Voltage - Supply, Dual (V±): ±4.5V ~ 16.5V
  • Switch Time (Ton, Toff) (Max): 170ns, 75ns
  • -3db Bandwidth: 200MHz
  • Charge Injection: -50pC
  • Channel Capacitance (CS(off), CD(off)): 12pF, 22pF
  • Current - Leakage (IS(off)) (Max): 300pA
  • Crosstalk: -70dB @ 1MHz
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 20-TSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 20-TSSOP
  • Base Part Number: ADG1434
  • detail: 4 Circuit IC Switch 2:1 4.7Ohm 20-TSSOP
