دیتاشیت ADP1763ACPZ-1.5-R7

ADP1763 Datasheet

مشخصات دیتاشیت

نام دیتاشیت ADP1763 Datasheet
حجم فایل 835.848 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

دانلود دیتاشیت ADP1763 Datasheet

ADP1763 Datasheet Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 1.98V
  • Voltage - Output (Min/Fixed): 1.5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.145V @ 3A
  • Current - Output: 3A
  • Current - Quiescent (Iq): 8mA
  • Current - Supply (Max): 16mA
  • PSRR: 62dB ~ 33dB (10kHz ~ 1MHz)
  • Control Features: Enable, Power Good, Soft Start
  • Protection Features: Current Limit, Thermal Overload
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 16-WFQFN Exposed Pad
  • Supplier Device Package: 16-LFCSP-WQ (3x3)
  • Base Part Number: ADP1763
  • detail: Linear Voltage Regulator IC 1 Output 3A 16-LFCSP-WQ (3x3)
