دیتاشیت TN0604N3-G
مشخصات دیتاشیت
| نام دیتاشیت |
TN0604
|
| حجم فایل |
626.65
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Microchip Tech TN0604N3-G
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
740mW
-
Drain Source Voltage (Vdss):
40V
-
Input Capacitance (Ciss@Vds):
190pF@20V
-
Continuous Drain Current (Id):
700mA
-
Gate Threshold Voltage (Vgs(th)@Id):
1.6V@1mA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
750mΩ@10V,1.5A
-
Package:
TO-92
-
Manufacturer:
Microchip Tech
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
40V
-
Current - Continuous Drain (Id) @ 25°C:
700mA (Tj)
-
Drive Voltage (Max Rds On, Min Rds On):
5V, 10V
-
Rds On (Max) @ Id, Vgs:
750mOhm @ 1.5A, 10V
-
Vgs(th) (Max) @ Id:
1.6V @ 1mA
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
190pF @ 20V
-
FET Feature:
-
-
Power Dissipation (Max):
740mW (Ta)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
TO-92-3
-
Package / Case:
TO-226-3, TO-92-3 (TO-226AA)
-
detail:
N-Channel 40V 700mA (Tj) 740mW (Ta) Through Hole TO-92-3
