20-TSSOP Pkg Drawing دیتاشیت

20-TSSOP Pkg Drawing

مشخصات دیتاشیت

نام دیتاشیت 20-TSSOP Pkg Drawing
حجم فایل 55.057 کیلوبایت
نوع فایل pdf
تعداد صفحات 1

دانلود دیتاشیت 20-TSSOP Pkg Drawing

دانلود دیتاشیت

سایر مستندات

AD7327-EP 14 pages

مشخصات فنی

  • Manufacturer: Analog Devices Inc.
  • Series: iCMOS®
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Number of Bits: 12
  • Sampling Rate (Per Second): 500k
  • Number of Inputs: 2, 3, 4
  • Input Type: Differential, Pseudo-Differential, Single Ended
  • Data Interface: SPI, DSP
  • Configuration: MUX-S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: ±12V ~ 16.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.25V
  • Features: Temperature Sensor, True Bipolar
  • Operating Temperature: -55°C ~ 125°C
  • Package / Case: 20-TSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 20-TSSOP
  • Mounting Type: Surface Mount
  • Base Part Number: AD7327
  • detail: 12 Bit Analog to Digital Converter 2, 3, 4 Input 1 SAR 20-TSSOP
