دیتاشیت MP3V5050DP

مشخصات دیتاشیت

دانلود دیتاشیت MP3V5050 Series	MP3V5050 Series Datasheet

Manufacturer: NXP USA Inc.
Series: MP3V5050
Part Status: Active
Applications: Board Mount
Pressure Type: Differential
Operating Pressure: 7.25PSI (50kPa)
Output Type: Analog Voltage
Output: 0.06 V ~ 2.82 V
Accuracy: ±2.5%
Voltage - Supply: 2.7V ~ 3.3V
Port Size: Male - 0.13" (3.3mm) Tube, Dual
Port Style: Barbed
Features: Temperature Compensated
Termination Style: Gull Wing
Maximum Pressure: 29.01PSI (200kPa)
Operating Temperature: -40°C ~ 125°C
Package / Case: 8-BSOP (0.475", 12.06mm Width) Dual Ports, Same Side
Supplier Device Package: 8-SOP
Base Part Number: MP3V5
detail: Pressure Sensor 7.25PSI (50kPa) Differential Male - 0.13" (3.3mm) Tube, Dual 0.06 V ~ 2.82 V 8-BSOP (0.475", 12.06mm Width) Dual Ports, Same Side
