مشخصات دیتاشیت

Tips N Tricks Guide	دانلود دیتاشیت

PIC16F526 122 pages

RoHS: true
CPU Core: PIC
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 8bit
Datasheet: Microchip Tech PIC16F526-I/ST
CPU Maximum Speed: 20MHz
GPIO Ports Number: 11
Low-Voltage Detect: Yes
Internal Oscillator: Yes
Program Storage Size: 1.5KB
Operating Voltage Range: 2V~5.5V
Operating Temperature Range: -40°C~+85°C
Package: TSSOP-14
Manufacturer: Microchip Tech
Series: PIC® 16F
Packaging: Tube
Part Status: Active
Core Processor: PIC
Core Size: 8-Bit
Speed: 20MHz
Connectivity: -
Peripherals: POR, WDT
Number of I/O: 11
Program Memory Size: 1.5KB (1K x 12)
Program Memory Type: FLASH
EEPROM Size: -
RAM Size: 67 x 8
Voltage - Supply (Vcc/Vdd): 2V ~ 5.5V
Data Converters: A/D 3x8b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 14-TSSOP (0.173", 4.40mm Width)
Supplier Device Package: 14-TSSOP
Base Part Number: PIC16F526
detail: PIC PIC® 16F Microcontroller IC 8-Bit 20MHz 1.5KB (1K x 12) FLASH 14-TSSOP
