دیتاشیت LP2951-02YN
مشخصات دیتاشیت
| نام دیتاشیت |
LP2951
|
| حجم فایل |
2774.73
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
30
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Microchip Tech LP2951-02YN
-
Output Current:
100mA
-
Output Voltage:
1.24V~29V
-
Dropout Voltage:
0.6V@(100mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
35V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
150uA
-
Package:
PDIP-8
-
Manufacturer:
Microchip Tech
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Adjustable (Fixed)
-
Number of Regulators:
1
-
Voltage - Input (Max):
30V
-
Voltage - Output (Min/Fixed):
1.24V (5V)
-
Voltage - Output (Max):
29V
-
Voltage Dropout (Max):
0.6V @ 100mA
-
Current - Output:
100mA
-
Current - Quiescent (Iq):
150µA
-
Current - Supply (Max):
14mA
-
PSRR:
-
-
Control Features:
Enable, Error Flag
-
Protection Features:
-
-
Mounting Type:
Through Hole
-
Package / Case:
8-DIP (0.300", 7.62mm)
-
Supplier Device Package:
8-PDIP
-
Base Part Number:
LP2951-02
-
detail:
Linear Voltage Regulator IC 1 Output 100mA 8-PDIP
