دیتاشیت MAX743CPE+
مشخصات دیتاشیت
| نام دیتاشیت |
MAX743
|
| حجم فایل |
4260.309
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost;Step-down-Boost
-
Output Type:
Adjustable
-
Input Voltage:
4.2V~6V
-
Output Voltage:
12V;15V
-
Number of Outputs:
2
-
Switching Frequency:
200kHz
-
Output Current (Max):
2A
-
Operating Temperature:
0°C~+70°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
PDIP-16
-
Manufacturer:
Analog Devices Inc./Maxim Integrated
-
Voltage - Input (Max):
6V
-
Voltage - Input (Min):
4.2V
-
Output Configuration:
Positive and Negative (Dual Rail)
-
Supplier Device Package:
16-PDIP
-
Package / Case:
16-DIP (0.300", 7.62mm)
-
Frequency - Switching:
200kHz
-
Current - Output:
2A (Switch)
-
Part Status:
Active
-
Series:
-
-
Voltage - Output (Max):
-
-
Base Part Number:
MAX743
-
Mounting Type:
Through Hole
-
Synchronous Rectifier:
No
-
Voltage - Output (Min/Fixed):
±12V, ±15V
-
Packaging:
Tube
-
detail:
Boost, Buck-Boost Switching Regulator IC Positive and Negative (Dual Rail) Programmable ±12V, ±15V 2 Output 2A (Switch) 16-DIP (0.300", 7.62mm)
