HYG025N06LS1B دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
HYG025N06LS1B
|
|
حجم فایل
|
66.206
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
HUAYI HYG025N06LS1B
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
125W
-
Total Gate Charge (Qg@Vgs):
27.7nC@10V
-
Drain Source Voltage (Vdss):
60V
-
Input Capacitance (Ciss@Vds):
3.915nF@25V
-
Continuous Drain Current (Id):
160A
-
Gate Threshold Voltage (Vgs(th)@Id):
2.1V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
10.2pF@25V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
2.5mΩ@10V,40A
-
Package:
TO-263
-
Manufacturer:
HUAYI
