دیتاشیت SG2525AN
مشخصات دیتاشیت
| نام دیتاشیت |
SGx525A
|
| حجم فایل |
956.625
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type;Buck-boost type
-
Topology:
Step-down;Push-pull
-
Datasheet:
STMicroelectronics SG2525AN
-
Output Type:
-
-
Number of Outputs:
2
-
Switching Frequency:
400kHz
-
Operating Temperature:
-25°C~+85°C@(TA)
-
Synchronous Rectification:
Yes
-
Package:
DIP-16
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Phases:
1
-
Voltage - Supply (Vcc/Vdd):
8V ~ 35V
-
Frequency - Switching:
100Hz ~ 400kHz
-
Duty Cycle (Max):
49%
-
Synchronous Rectifier:
Yes
-
Clock Sync:
Yes
-
Serial Interfaces:
-
-
Control Features:
Enable, Soft Start
-
Mounting Type:
Through Hole
-
Package / Case:
16-DIP (0.300", 7.62mm)
-
Supplier Device Package:
16-DIP
-
Base Part Number:
SG2525
-
detail:
Buck, Push-Pull Regulator Positive Output Step-Down, Step-Up/Step-Down DC-DC Controller IC 16-DIP
