دیتاشیت MAX4524CUB

MAX4524-25

مشخصات دیتاشیت

نام دیتاشیت MAX4524-25
حجم فایل 355.682 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت MAX4524-25

MAX4524-25 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 4:1
  • Part Status: Obsolete
  • Charge Injection: 0.8pC
  • -3db Bandwidth: -
  • Operating Temperature: 0°C ~ 70°C (TA)
  • Voltage - Supply, Dual (V±): -
  • Supplier Device Package: 10-uMAX
  • Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
  • Switch Time (Ton, Toff) (Max): 150ns, 120ns
  • Packaging: Tube
  • Channel-to-Channel Matching (ΔRon): 2Ohm
  • Voltage - Supply, Single (V+): 2V ~ 12V
  • Channel Capacitance (CS(off), CD(off)): 4pF, 14pF
  • Switch Circuit: SP4T
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -
  • Number of Circuits: 1
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 1nA
  • Base Part Number: MAX4524
  • On-State Resistance (Max): 150Ohm
  • detail: 1 Circuit IC Switch 4:1 150Ohm 10-uMAX
