دیتاشیت MAX515CPA

MAX504,515

مشخصات دیتاشیت

نام دیتاشیت MAX504,515
حجم فایل 178.954 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت MAX504,515

MAX504,515 Datasheet

مشخصات

  • Operating Temperature: 0°C ~ 70°C
  • Mounting Type: Through Hole
  • Number of D/A Converters: 1
  • Data Interface: SPI
  • Voltage - Supply, Digital: 5V
  • Reference Type: External
  • Number of Bits: 10
  • Part Status: Obsolete
  • INL/DNL (LSB): ±0.5 (Max), ±1 (Max)
  • Differential Output: No
  • Output Type: Voltage - Buffered
  • Series: -
  • Voltage - Supply, Analog: 5V
  • Base Part Number: MAX515
  • Supplier Device Package: 8-PDIP
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Settling Time: 25µs (Typ)
  • Packaging: Tube
  • Architecture: R-2R
  • Manufacturer: Maxim Integrated
  • detail: 10 Bit Digital to Analog Converter 1 8-PDIP
