دیتاشیت BDW42
مشخصات دیتاشیت
| نام دیتاشیت |
BDW42(46,47)
|
| حجم فایل |
85.317
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Pre-ordered transistors
-
Package:
TO-220
-
Manufacturer:
SPTECH
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Transistor Type:
NPN - Darlington
-
Current - Collector (Ic) (Max):
15A
-
Voltage - Collector Emitter Breakdown (Max):
100V
-
Vce Saturation (Max) @ Ib, Ic:
3V @ 50mA, 10A
-
Current - Collector Cutoff (Max):
2mA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
1000 @ 5A, 4V
-
Power - Max:
85W
-
Frequency - Transition:
4MHz
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3
-
Supplier Device Package:
TO-220AB
-
Base Part Number:
BDW42
-
detail:
Bipolar (BJT) Transistor NPN - Darlington 100V 15A 4MHz 85W Through Hole TO-220AB
