دیتاشیت IXTP140P05T
مشخصات دیتاشیت
| نام دیتاشیت | IXT(A,H,P)140P05T |
|---|---|
| حجم فایل | 223.894 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 7 |
دانلود دیتاشیت IXT(A,H,P)140P05T |
IXT(A,H,P)140P05T Datasheet |
|---|
مشخصات
- Manufacturer: IXYS
- Series: TrenchP™
- Packaging: Tube
- Part Status: Active
- FET Type: P-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 50V
- Current - Continuous Drain (Id) @ 25°C: 140A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 10V
- Rds On (Max) @ Id, Vgs: 9mOhm @ 70A, 10V
- Vgs(th) (Max) @ Id: 4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 200nC @ 10V
- Vgs (Max): ±15V
- Input Capacitance (Ciss) (Max) @ Vds: 13500pF @ 25V
- FET Feature: -
- Power Dissipation (Max): 298W (Tc)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: TO-220AB
- Package / Case: TO-220-3
