دیتاشیت IXFK20N80Q

IXF(H,K,T)20N80Q

مشخصات دیتاشیت

نام دیتاشیت IXF(H,K,T)20N80Q
حجم فایل 207.262 کیلوبایت
نوع فایل pdf
تعداد صفحات 3

دانلود دیتاشیت IXF(H,K,T)20N80Q

IXF(H,K,T)20N80Q Datasheet

مشخصات

  • Manufacturer: IXYS
  • Series: HiPerFET™
  • Packaging: Tube
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 800V
  • Current - Continuous Drain (Id) @ 25°C: 20A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 420mOhm @ 10A, 10V
  • Vgs(th) (Max) @ Id: 4.5V @ 4mA
  • Gate Charge (Qg) (Max) @ Vgs: 200nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 5100pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 360W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-264AA (IXFK)
  • Package / Case: TO-264-3, TO-264AA
  • detail: N-Channel 800V 20A (Tc) 360W (Tc) Through Hole TO-264AA (IXFK)
