IXFK20N80Q

IXFK20N80Q

IXFK20N80Q

در 2 فروشگاه

مشخصات فنی:
ManufacturerIXYS
PackageTO-264-3, TO-264AA
Datasheet IXF(H,K,T)20N80Q
Description N-Channel 800V 20A (Tc) 360W (Tc) Through Hole TO-264AA (IXFK)
تغییرات قیمت
مشخصات
  • Manufacturer IXYS
  • Series HiPerFET™
  • Packaging Tube
  • Part Status Obsolete
  • FET Type N-Channel
  • Technology MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss) 800V
  • Current - Continuous Drain (Id) @ 25°C 20A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On) 10V
  • Rds On (Max) @ Id, Vgs 420mOhm @ 10A, 10V
  • Vgs(th) (Max) @ Id 4.5V @ 4mA
  • Gate Charge (Qg) (Max) @ Vgs 200nC @ 10V
  • Vgs (Max) ±20V
  • Input Capacitance (Ciss) (Max) @ Vds 5100pF @ 25V
  • FET Feature -
  • Power Dissipation (Max) 360W (Tc)
  • Operating Temperature -55°C ~ 150°C (TJ)
  • Mounting Type Through Hole
  • Supplier Device Package TO-264AA (IXFK)
  • Package / Case TO-264-3, TO-264AA
  • detail N-Channel 800V 20A (Tc) 360W (Tc) Through Hole TO-264AA (IXFK)
