دیتاشیت NDUL03N150CG

NDUL03N150C

مشخصات دیتاشیت

نام دیتاشیت NDUL03N150C
حجم فایل 261.775 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت NDUL03N150C

NDUL03N150C Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 1500V
  • Current - Continuous Drain (Id) @ 25°C: 2.5A (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 10.5Ohm @ 1.25A, 10V
  • Vgs(th) (Max) @ Id: -
  • Gate Charge (Qg) (Max) @ Vgs: 34nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 650pF @ 30V
  • FET Feature: -
  • Power Dissipation (Max): 3W (Ta), 50W (Tc)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-3P(L)
  • Package / Case: TO-3PL
  • Base Part Number: NDUL03
