LD29150DT33R دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LD29150DT33R
|
|
حجم فایل
|
58.533
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
23
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
STMicroelectronics LD29150DT33R
-
Output Type:
Fixed
-
Output Current:
1.5A
-
Output Voltage:
3.3V
-
Dropout Voltage:
700mV@(1.5A)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
14V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
180uA
-
Power Supply Rejection Ratio (PSRR):
67dB@(120Hz)
-
Package:
TO-252-2(DPAK)
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
14V
-
Voltage - Output (Min/Fixed):
3.3V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.7V @ 1.5A
-
Current - Output:
1.5A
-
Current - Quiescent (Iq):
180µA
-
Current - Supply (Max):
80mA
-
PSRR:
67dB (120Hz)
-
Control Features:
-
-
Protection Features:
Over Current, Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Supplier Device Package:
DPAK
-
Base Part Number:
LD29150
-
detail:
Linear Voltage Regulator IC 1 Output 1.5A DPAK
