دیتاشیت ISO7220CDR
مشخصات دیتاشیت
| نام دیتاشیت | ISO7220-21A/B/C/M |
|---|---|
| حجم فایل | 1401.973 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 38 |
دانلود دیتاشیت ISO7220-21A/B/C/M |
ISO7220-21A/B/C/M Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 25Mbps
- Datasheet: Texas Instruments ISO7220CDR
- Applications: General-purpose
- Supply Voltage: 2.8V~5.5V
- Forward Channel: 2
- Reverse channel: 0
- Number of Channels: 2
- Isolation Technology: 电容隔离
- Operating Temperature: -40°C~+125°C
- Voltage Isolation or Not: 带电压隔离
- Package: SOP-8
- Manufacturer: Texas Instruments
- Inputs - Side 1/Side 2: 2/0
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Rise / Fall Time (Typ): 1ns, 1ns
- Type: General Purpose
- Packaging: Cut Tape (CT)
- Supplier Device Package: 8-SOIC
- Part Status: Active
- Common Mode Transient Immunity (Min): 25kV/µs
- Base Part Number: ISO7220
- Pulse Width Distortion (Max): 2ns
- Isolated Power: No
- Channel Type: Unidirectional
- Voltage - Supply: 2.8V ~ 5.5V
- Series: -
- Propagation Delay tpLH / tpHL (Max): 42ns, 42ns
- Mounting Type: Surface Mount
- Voltage - Isolation: 2500Vrms
- Technology: Capacitive Coupling
- detail: General Purpose Digital Isolator 2500Vrms 2 Channel 25Mbps 25kV/µs CMTI 8-SOIC (0.154", 3.90mm Width)
