دیتاشیت P6KE180A
مشخصات دیتاشیت
| نام دیتاشیت |
P6KE
|
| حجم فایل |
138.669
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/TVS
-
Datasheet:
DOWO P6KE180A
-
Breakdown Voltage:
171V
-
Maximum Clamping Voltage:
246V
-
Reverse Stand-Off Voltage (Vrwm):
154V
-
Peak Pulse Current (Ipp)@10/1000us:
2.44A
-
Package:
DO-15
-
Manufacturer:
DOWO
-
Unidirectional Channels:
1
-
Peak Pulse Power Dissipation (Ppp)@10/1000us:
600W
-
Reverse Leakage Current (Ir):
5uA
-
Peak Pulse Current (Ipp)@10/1000μs:
2.5A
-
Peak Pulse Power Dissipation (Ppp)@10/1000μs:
600W
-
Series:
P6KE, TRANSIL™
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Zener
-
Voltage - Reverse Standoff (Typ):
154V
-
Voltage - Breakdown (Min):
171V
-
Voltage - Clamping (Max) @ Ipp:
317V
-
Current - Peak Pulse (10/1000µs):
12.6A (8/20µs)
-
Power - Peak Pulse:
600W
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
360pF @ 1MHz
-
Operating Temperature:
-
-
Mounting Type:
Through Hole
-
Package / Case:
DO-204AC, DO-15, Axial
-
Supplier Device Package:
DO-15
-
Base Part Number:
P6KE
-
detail:
317V Clamp 12.6A (8/20µs) Ipp Tvs Diode Through Hole DO-15
