دیتاشیت F28M36P63C2ZWTT
مشخصات دیتاشیت
| نام دیتاشیت |
F28M36Px3B2,C2
|
| حجم فایل |
2409.978
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
253
|
مشخصات
-
RoHS:
true
-
EEPROM:
-
-
CPU Core:
ARM-MSeries
-
Category:
Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
-
RAM Size:
-
-
Watchdog:
Yes
-
ADC (Bit):
12bit
-
DAC (Bit):
-
-
Datasheet:
Texas Instruments F28M36P63C2ZWTT
-
PWM (Bit):
-
-
Real-Time Clock:
-
-
CPU Maximum Speed:
125MHz;150MHz
-
GPIO Ports Number:
142
-
Low-Voltage Detect:
Yes
-
CCP Capture/Compare:
-
-
Internal Comparator:
-
-
Internal Oscillator:
Yes
-
Peripheral/Function:
PWM
-
Program Memory Type:
-
-
Direct Memory Access:
Yes
-
Program Storage Size:
-
-
Universal Serial Bus:
Yes
-
communication protocol:
-
-
Operating Voltage Range:
1.14V~3.46V
-
Infrared Data Association:
Yes
-
Operating Temperature Range:
-40°C~+105°C
-
Secure Digital Input and Output:
-
-
Package:
BGA-289
-
Manufacturer:
Texas Instruments
-
Mounting Type:
Surface Mount
-
Connectivity:
CANbus, EBI/EMI, Ethernet, I²C, IrDA, McBSP, SCI, SPI, SSI, UART/USART, USB OTG
-
Packaging:
Tray
-
Data Converters:
A/D 24x12b
-
Number of I/O:
142
-
Core Size:
32-Bit Dual-Core
-
Core Processor:
C28x/ARM® Cortex®-M3
-
Supplier Device Package:
289-NFBGA (16x16)
-
Operating Temperature:
-40°C ~ 105°C (TJ)
-
Part Status:
Active
-
EEPROM Size:
-
-
Package / Case:
289-LFBGA
-
Voltage - Supply (Vcc/Vdd):
1.14V ~ 3.46V
-
Program Memory Size:
512KB/1MB
-
Base Part Number:
F28M36
-
Speed:
125MHz/150MHz
-
Series:
C2000™ C28x + ARM® Cortex® M3 Concerto™
-
Oscillator Type:
Internal
-
Peripherals:
Brown-out Detect/Reset, DMA, POR, PWM, WDT
-
detail:
C28x/ARM® Cortex®-M3 C2000™ C28x + ARM® Cortex® M3 Concerto™ Microcontroller IC 32-Bit Dual-Core 125MHz/150MHz 512KB/1MB FLASH 289-NFBGA (16x16)
