دیتاشیت UC2844AN
مشخصات دیتاشیت
| نام دیتاشیت |
UCx84xA
|
| حجم فایل |
171.509
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
16
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/AC-DC Controllers & Regulators
-
Topology:
Boost;Step-down;Flyback;Forward
-
Datasheet:
Texas Instruments UC2844AN
-
Duty Cycle:
48%
-
Supply Voltage:
10V~30V
-
Switching Frequency:
500kHz
-
Operating Temperature:
-40°C~+85°C@(Ta)
-
Package:
DIP-8
-
Manufacturer:
Texas Instruments
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Output Type:
Transistor Driver
-
Function:
Step-Up, Step-Down, Step-Up/Step-Down
-
Output Configuration:
Positive
-
Number of Outputs:
1
-
Output Phases:
1
-
Voltage - Supply (Vcc/Vdd):
10V ~ 30V
-
Frequency - Switching:
Up to 500kHz
-
Duty Cycle (Max):
48%
-
Synchronous Rectifier:
No
-
Clock Sync:
No
-
Serial Interfaces:
-
-
Control Features:
Frequency Control
-
Mounting Type:
Through Hole
-
Package / Case:
8-DIP (0.300", 7.62mm)
-
Supplier Device Package:
8-Mini DIP
-
Base Part Number:
UC2844
-
detail:
Boost, Buck, Buck-Boost, Flyback, Forward Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 8-Mini DIP
