دیتاشیت MTP50P03HDL
مشخصات دیتاشیت
| نام دیتاشیت |
MTP50P03HDL
|
| حجم فایل |
89.492
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
FET Type:
P-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
30V
-
Current - Continuous Drain (Id) @ 25°C:
50A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
5V
-
Rds On (Max) @ Id, Vgs:
25mOhm @ 25A, 5V
-
Vgs(th) (Max) @ Id:
2V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
100nC @ 5V
-
Vgs (Max):
±15V
-
Input Capacitance (Ciss) (Max) @ Vds:
4900pF @ 25V
-
FET Feature:
-
-
Power Dissipation (Max):
125W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
TO-220AB
-
Package / Case:
TO-220-3
-
Base Part Number:
MTP50
-
detail:
P-Channel 30V 50A (Tc) 125W (Tc) Through Hole TO-220AB
