MTP50P03HDL
در 0 فروشگاه
قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | ON Semiconductor |
| Package | TO-220-3 |
| Datasheet | MTP50P03HDL |
| Description | P-Channel 30V 50A (Tc) 125W (Tc) Through Hole TO-220AB |
sellers MTP50P03HDL
فروشگاهی یافت نشد
تغییرات قیمت
مشخصات MTP50P03HDL
- Manufacturer ON Semiconductor
- Series -
- Packaging Tube
- Part Status Obsolete
- FET Type P-Channel
- Technology MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss) 30V
- Current - Continuous Drain (Id) @ 25°C 50A (Tc)
- Drive Voltage (Max Rds On, Min Rds On) 5V
- Rds On (Max) @ Id, Vgs 25mOhm @ 25A, 5V
- Vgs(th) (Max) @ Id 2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs 100nC @ 5V
- Vgs (Max) ±15V
- Input Capacitance (Ciss) (Max) @ Vds 4900pF @ 25V
- FET Feature -
- Power Dissipation (Max) 125W (Tc)
- Operating Temperature -55°C ~ 150°C (TJ)
- Mounting Type Through Hole
- Supplier Device Package TO-220AB
- Package / Case TO-220-3
- Base Part Number MTP50
- detail P-Channel 30V 50A (Tc) 125W (Tc) Through Hole TO-220AB
