دیتاشیت ACS108-6SN-TR

ACS108-6SN

مشخصات دیتاشیت

نام دیتاشیت ACS108-6SN
حجم فایل 299.005 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت ACS108-6SN

ACS108-6SN Datasheet

مشخصات

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/TRIACs
  • SCR Type: 门极灵敏型-High Speed
  • Datasheet: STMicroelectronics ACS108-6SN-TR
  • Holding Current (Ih): 25mA
  • Operating Temperature: -30°C~+125°C@(Tj)
  • Gate Trigger Current(Igt): 10mA
  • Gate Trigger Voltage (Vgt): 1V
  • RMS On-State Current(It (rms)): 800mA
  • Peak Repetitive Off?State Voltage (Vdrm): 600V
  • Package: SOT-223
  • Manufacturer: STMicroelectronics
  • Series: ACS™/A.S.D®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Triac Type: Logic - Sensitive Gate
  • Voltage - Off State: 600V
  • Current - On State (It (RMS)) (Max): 800mA
  • Voltage - Gate Trigger (Vgt) (Max): 1V
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 7.3A, 7.6A
  • Current - Gate Trigger (Igt) (Max): 10mA
  • Current - Hold (Ih) (Max): 25mA
  • Configuration: Single
  • Mounting Type: Surface Mount
  • Package / Case: TO-261-4, TO-261AA
  • Supplier Device Package: SOT-223
  • Base Part Number: ACS108
  • detail: TRIAC Logic - Sensitive Gate 600V 800mA Surface Mount SOT-223
