- UC2844AN
UC2844AN Datasheet
Datasheet specifications
| Datasheet's name | UC2844AN |
|---|---|
| File size | 87.575 KB |
| File type | |
| Number of pages | 48 |
Download Datasheet UC2844AN |
Download Datasheet |
|---|
Other documentations
UC2842A(43A), UC3842A(43A) 18 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/AC-DC Controllers & Regulators
- Topology: Boost;Step-down;Flyback;Forward
- Datasheet: Texas Instruments UC3842AN
- Duty Cycle: 96%
- Supply Voltage: 10V~30V
- Switching Frequency: 500kHz
- Operating Temperature: 0°C~+70°C@(Ta)
- Package: DIP-8
- Manufacturer: Texas Instruments
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Output Type: Transistor Driver
- Function: Step-Up, Step-Up/Step-Down
- Output Configuration: Positive
- Number of Outputs: 1
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 10V ~ 30V
- Frequency - Switching: Up to 500kHz
- Duty Cycle (Max): 96%
- Synchronous Rectifier: No
- Clock Sync: No
- Serial Interfaces: -
- Control Features: Frequency Control
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-PDIP
- Base Part Number: UC384
- detail: Boost, Flyback Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-PDIP
