دیتاشیت FDA50N50

FDA50N50, FDH50N50

مشخصات دیتاشیت

نام دیتاشیت FDA50N50, FDH50N50
حجم فایل 468.364 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

دانلود دیتاشیت FDA50N50, FDH50N50

FDA50N50, FDH50N50 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: UniFET™
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 500V
  • Current - Continuous Drain (Id) @ 25°C: 48A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 105mOhm @ 24A, 10V
  • Vgs(th) (Max) @ Id: 5V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 137nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 6460pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 625W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-3PN
  • Package / Case: TO-3P-3, SC-65-3
  • Base Part Number: FDA50
  • detail: N-Channel 500V 48A (Tc) 625W (Tc) Through Hole TO-3PN
