دیتاشیت ADG608BRZ

ADG608,609

مشخصات دیتاشیت

نام دیتاشیت ADG608,609
حجم فایل 164.506 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت ADG608,609

ADG608,609 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Switch Circuit: -
  • Multiplexer/Demultiplexer Circuit: 8:1
  • Number of Circuits: 1
  • On-State Resistance (Max): 30Ohm
  • Channel-to-Channel Matching (ΔRon): 5Ohm (Max)
  • Voltage - Supply, Single (V+): 3.3V ~ 5V
  • Voltage - Supply, Dual (V±): ±5V
  • Switch Time (Ton, Toff) (Max): 75ns, 45ns
  • -3db Bandwidth: -
  • Charge Injection: 6pC
  • Channel Capacitance (CS(off), CD(off)): 9pF, 40pF
  • Current - Leakage (IS(off)) (Max): 500pA
  • Crosstalk: -85dB @ 100kHz
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 16-SOIC
  • Base Part Number: ADG608
  • detail: 1 Circuit IC Switch 8:1 30Ohm 16-SOIC
