STGF15H60DF
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | STMicroelectronics |
| Package | TO-220-3 Full Pack |
| Datasheet | STGx15H60DF |
| Description | IGBT Trench Field Stop 600V 30A 30W Through Hole TO-220FP |
فروشنده های STGF15H60DF
فروشگاهی یافت نشد
تغییرات قیمت
مشخصات STGF15H60DF
- RoHS true
- Type Trench Field Stop
- Category Triode/MOS Tube/Transistor/IGBTs
- Datasheet STMicroelectronics STGF15H60DF
- Operating Temperature 55°C~+175°C@(Tj)
- Collector Current (Ic) 30A
- Power Dissipation (Pd) 30W
- Turn?on Delay Time (Td(on)) 24.5ns
- Total Gate Charge (Qg@Ic,Vge) 81nC
- Turn?off Delay Time (Td(off)) 118ns
- Pulsed Collector Current (Icm) 60A
- Diode Reverse Recovery Time (Trr) 103ns
- Collector-Emitter Breakdown Voltage (Vces) 600V
- Gate-Emitter Threshold Voltage (Vge(th)@Ic) 2V@15V,15A
- Package TO-220
- Manufacturer STMicroelectronics
- Series -
- Packaging Tube
- Part Status Active
- IGBT Type Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max) 600V
- Current - Collector (Ic) (Max) 30A
- Current - Collector Pulsed (Icm) 60A
- Vce(on) (Max) @ Vge, Ic 2V @ 15V, 15A
- Power - Max 30W
- Switching Energy 136µJ (on), 207µJ (off)
- Input Type Standard
- Gate Charge 81nC
- Td (on/off) @ 25°C 24.5ns/118ns
- Test Condition 400V, 15A, 10Ohm, 15V
- Reverse Recovery Time (trr) 103ns
- Mounting Type Through Hole
- Package / Case TO-220-3 Full Pack
- Supplier Device Package TO-220FP
- Base Part Number STGF15
- detail IGBT Trench Field Stop 600V 30A 30W Through Hole TO-220FP
