LM2698MM-ADJ/NOPB
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Texas Instruments |
| Package | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
| Datasheet | LM2698 |
| Description | Boost, SEPIC Switching Regulator IC Positive or Negative Adjustable 2.2V 1 Output 1.35A (Switch) 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
فروشنده های LM2698MM-ADJ/NOPB
فروشگاهی یافت نشد
مشخصات LM2698MM-ADJ/NOPB
- RoHS true
- Category Power Supply Chip/DC-DC Converters
- Function boost converterType;Buck-boost type
- Topology Boost;SEPIC
- Datasheet Texas Instruments LM2698MM-ADJ/NOPB
- Output Type Adjustable
- Input Voltage 2.2V~12V
- Output Voltage 2.2V~17.5V
- Number of Outputs 1
- Switching Frequency 600kHz;1.25MHz
- Output Current (Max) 1.35A
- Operating Temperature -40°C~+125°C@(TJ)
- Synchronous Rectification NO
- Package MSOP-8
- Manufacturer Texas Instruments
- Frequency - Switching 600kHz, 1.25MHz
- Package / Case 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Supplier Device Package 8-VSSOP
- Voltage - Output (Min/Fixed) 2.2V
- Current - Output 1.35A (Switch)
- Output Configuration Positive or Negative
- Packaging Cut Tape (CT)
- Part Status Active
- Voltage - Output (Max) 17.5V
- Series SIMPLE SWITCHER®
- Mounting Type Surface Mount
- Voltage - Input (Max) 12V
- Base Part Number LM2698
- Voltage - Input (Min) 2.2V
- Synchronous Rectifier No
- detail Boost, SEPIC Switching Regulator IC Positive or Negative Adjustable 2.2V 1 Output 1.35A (Switch) 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
