مشخصات STB80NF55L-08-1
- Manufacturer STMicroelectronics
- Series STripFET™ II
- Packaging Tube
- Part Status Obsolete
- FET Type N-Channel
- Technology MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss) 55V
- Current - Continuous Drain (Id) @ 25°C 80A (Tc)
- Drive Voltage (Max Rds On, Min Rds On) 5V, 10V
- Rds On (Max) @ Id, Vgs 8mOhm @ 40A, 10V
- Vgs(th) (Max) @ Id 2.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs 100nC @ 4.5V
- Vgs (Max) ±16V
- Input Capacitance (Ciss) (Max) @ Vds 4350pF @ 25V
- FET Feature -
- Power Dissipation (Max) 300W (Tc)
- Operating Temperature 175°C (TJ)
- Mounting Type Through Hole
- Supplier Device Package I2PAK
- Package / Case TO-262-3 Long Leads, I²Pak, TO-262AA
- Base Part Number STB80N
- detail N-Channel 55V 80A (Tc) 300W (Tc) Through Hole I2PAK
