ADG1211YCPZ-500RL7
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | Analog Devices |
| Package | 16-WFQFN Exposed Pad, CSP |
| Datasheet | ADG1211-13 |
| Description | 1 Circuit IC Switch 1:1 190Ohm 16-LFCSP-WQ (3x3) |
فروشنده های ADG1211YCPZ-500RL7
فروشگاهی یافت نشد
مشخصات ADG1211YCPZ-500RL7
- RoHS true
- Category Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet Analog Devices ADG1211YCPZ-500RL7
- Turn-on time 130ns
- Turn-off time 115ns
- Supply Voltage 5V~16.5V
- Switch Circuit SPST(SPST)-Normally closed
- Number of Channels 4
- On-State Resistance (Max) 190Ω
- Package LFCSP-16
- Manufacturer Analog Devices
- Series -
- Packaging Cut Tape (CT)
- Part Status Active
- Multiplexer/Demultiplexer Circuit 1:1
- Number of Circuits 1
- Channel-to-Channel Matching (ΔRon) 2.5Ohm
- Voltage - Supply, Single (V+) 5V ~ 16.5V
- Voltage - Supply, Dual (V±) ±4.5V ~ 16.5V
- Switch Time (Ton, Toff) (Max) 130ns, 115ns
- -3db Bandwidth 1GHz
- Charge Injection -0.3pC
- Channel Capacitance (CS(off), CD(off)) 1.1pF, 1.2pF
- Current - Leakage (IS(off)) (Max) 100pA
- Crosstalk -90dB @ 1MHz
- Operating Temperature -40°C ~ 125°C (TA)
- Mounting Type Surface Mount
- Package / Case 16-WFQFN Exposed Pad, CSP
- Supplier Device Package 16-LFCSP-WQ (3x3)
- Base Part Number ADG1211
- detail 1 Circuit IC Switch 1:1 190Ohm 16-LFCSP-WQ (3x3)
