TIL111
در 1 فروشگاه
| Manufacturer | ON Semiconductor |
| Package | 6-DIP (0.300", 7.62mm) |
| Datasheet | TIL111M,117M, MOC8100M |
| Description | --- |
تغییرات قیمت
مشخصات
- Manufacturer ON Semiconductor
- Series -
- Packaging Tube
- Part Status Obsolete
- Number of Channels 1
- Voltage - Isolation 5300Vrms
- Current Transfer Ratio (Min) -
- Current Transfer Ratio (Max) -
- Turn On / Turn Off Time (Typ) -
- Rise / Fall Time (Typ) 10µs, 10µs (Max)
- Input Type DC
- Output Type Transistor with Base
- Voltage - Output (Max) 30V
- Current - Output / Channel 2mA
- Voltage - Forward (Vf) (Typ) 1.2V
- Current - DC Forward (If) (Max) 100mA
- Vce Saturation (Max) 400mV
- Operating Temperature -55°C ~ 100°C
- Mounting Type Through Hole
- Package / Case 6-DIP (0.300", 7.62mm)
- Supplier Device Package 6-DIP
- Base Part Number TIL111
