IXFK80N60P3

IXFK80N60P3

IXFK80N60P3

در 2 فروشگاه

مشخصات فنی:
ManufacturerIXYS
PackageTO-264-3, TO-264AA
Datasheet IXFK-FX80N60P3
Description N-Channel 600V 80A (Tc) 1300W (Tc) Through Hole TO-264AA (IXFK)
تغییرات قیمت
مشخصات
  • Manufacturer IXYS
  • Series HiPerFET™, Polar3™
  • Packaging Tube
  • Part Status Active
  • FET Type N-Channel
  • Technology MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss) 600V
  • Current - Continuous Drain (Id) @ 25°C 80A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On) 10V
  • Rds On (Max) @ Id, Vgs 70mOhm @ 500mA, 10V
  • Vgs(th) (Max) @ Id 5V @ 8mA
  • Gate Charge (Qg) (Max) @ Vgs 190nC @ 10V
  • Vgs (Max) ±30V
  • Input Capacitance (Ciss) (Max) @ Vds 13100pF @ 25V
  • FET Feature -
  • Power Dissipation (Max) 1300W (Tc)
  • Operating Temperature -55°C ~ 150°C (TJ)
  • Mounting Type Through Hole
  • Supplier Device Package TO-264AA (IXFK)
  • Package / Case TO-264-3, TO-264AA
  • detail N-Channel 600V 80A (Tc) 1300W (Tc) Through Hole TO-264AA (IXFK)
