مشخصات
- ON SemiconductorManufacturer
- -Series
- TubePackaging
- ActivePart Status
- Trench Field StopIGBT Type
- 1000VVoltage - Collector Emitter Breakdown (Max)
- 80ACurrent - Collector (Ic) (Max)
- 120ACurrent - Collector Pulsed (Icm)
- 2.3V @ 15V, 40AVce(on) (Max) @ Vge, Ic
- 333WPower - Max
- 2.35mJ (on), 1.15mJ (off)Switching Energy
- StandardInput Type
- 265nCGate Charge
- 29ns/285nsTd (on/off) @ 25°C
- 600V, 40A, 10Ohm, 15VTest Condition
- 78nsReverse Recovery Time (trr)
- -55°C ~ 175°C (TJ)Operating Temperature
- Through HoleMounting Type
- TO-247-3Package / Case
- TO-247-3Supplier Device Package
- FGH40Base Part Number
- IGBT Trench Field Stop 1000V 80A 333W Through Hole TO-247-3detail
