FOD8173T
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | onsemi |
| Package | 6-SOIC (0.268", 6.80mm Width) |
| Datasheet | FOD8173(T) |
| Description | Logic Output Optoisolator 20Mbps Push-Pull, Totem Pole 5000Vrms 1 Channel 20kV/µs CMTI 6-SOP |
فروشنده های FOD8173T
فروشگاهی یافت نشد
تغییرات قیمت
مشخصات FOD8173T
- RoHS true
- Category Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Phototransistor Output
- Datasheet onsemi FOD8173T
- Fall time 3us@2mA,100Ω
- Rise time 4us@2mA,100Ω
- Output Type Phototransistor
- Output Current 50mA
- Forward Voltage 1.2V
- Reverse Voltage 6V
- Number of Outputs 1
- Input voltage type DC
- Operating Temperature -55°C~+110°C
- Receiving End Voltage 70V
- Isolation Voltage(rms) 5000V
- Collector-Emitter Saturation Voltage (Vce(sat)@Ic,IF) 0.1V@1mA,20mA
- Package SOP-6-4.6mm
- Manufacturer onsemi
- Series -
- Packaging Tube
- Part Status Active
- Number of Channels 1
- Inputs - Side 1/Side 2 1/0
- Voltage - Isolation 5000Vrms
- Common Mode Transient Immunity (Min) 20kV/µs
- Input Type DC
- Current - Output / Channel 10mA
- Data Rate 20Mbps
- Propagation Delay tpLH / tpHL (Max) 55ns, 55ns
- Rise / Fall Time (Typ) 7ns, 7ns
- Voltage - Forward (Vf) (Typ) 1.35V
- Current - DC Forward (If) (Max) 20mA
- Voltage - Supply 3V ~ 5.5V
- Mounting Type Surface Mount
- Package / Case 6-SOIC (0.268", 6.80mm Width)
- Supplier Device Package 6-SOP
- Base Part Number FOD817
- detail Logic Output Optoisolator 20Mbps Push-Pull, Totem Pole 5000Vrms 1 Channel 20kV/µs CMTI 6-SOP
