MMBT2222ALT1
در 1 فروشگاه از 374 تا 374 تومان
| Manufacturer | LGE |
| Package | TO-236-3, SC-59, SOT-23-3 |
| Datasheet | MMBT/SMMBT2222(A)L Datasheet |
| Description | --- |
فروشنده های MMBT2222ALT1
| قیمت | |||
| MMBT2222ALT1 | 374 تومان |
خرید اینترنتی
آخرین تغییر قیمت فروشگاه:
|
تغییرات قیمت
مشخصات MMBT2222ALT1
- RoHS true
- Category Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet LGE MMBT2222ALT1
- Transistor Type NPN
- Operating Temperature -55°C~+150°C@(Tj)
- Collector Current (Ic) 600mA
- Power Dissipation (Pd) 300mW
- Transition Frequency (fT) 300MHz
- DC Current Gain (hFE@Ic,Vce) 100@150mA,10V
- Collector Cut-Off Current (Icbo) 10nA
- Collector-Emitter Breakdown Voltage (Vceo) 40V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib) 300mV@150mA,15mA
- Package SOT-23(TO-236)
- Manufacturer LGE
- Series -
- Packaging Cut Tape (CT)
- Part Status Obsolete
- Current - Collector (Ic) (Max) 600mA
- Voltage - Collector Emitter Breakdown (Max) 40V
- Vce Saturation (Max) @ Ib, Ic 1V @ 50mA, 500mA
- Current - Collector Cutoff (Max) 10nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 150mA, 10V
- Power - Max 225mW
- Frequency - Transition 300MHz
- Mounting Type Surface Mount
- Package / Case TO-236-3, SC-59, SOT-23-3
- Supplier Device Package SOT-23-3 (TO-236)
- Base Part Number MMBT2222
