SM4T26CAY
در 0 فروشگاه قیمت هنوز مشخص نشده است
این محصول در حال حاضر فروشنده ای ندارد!
| Manufacturer | STMicroelectronics |
| Package | DO-214AC, SMA |
| Datasheet | SM4TY |
| Description | 48.3V Clamp 48A (8/20µs) Ipp Tvs Diode Surface Mount SMA (DO-214AC) |
فروشنده های SM4T26CAY
فروشگاهی یافت نشد
تغییرات قیمت
مشخصات SM4T26CAY
- RoHS true
- Category TVS/Fuse/Board Level Protection/TVS
- Datasheet STMicroelectronics SM4T26CAY
- Breakdown Voltage 24.4V
- Bidirectional Channels 1
- Maximum Clamping Voltage 48.3V
- Reverse Leakage Current (Ir) 0.2uA
- Reverse Stand-Off Voltage (Vrwm) 22V
- Peak Pulse Current (Ipp)@10/1000us 48A@8/20us
- Peak Pulse Power Dissipation (Ppp)@10/1000us 400W
- Package SMA(DO-214AC)
- Manufacturer STMicroelectronics
- Series Automotive, AEC-Q101, SM4TY, TRANSIL™
- Packaging Cut Tape (CT)
- Part Status Active
- Type Zener
- Voltage - Reverse Standoff (Typ) 22V
- Voltage - Breakdown (Min) 24.4V
- Voltage - Clamping (Max) @ Ipp 48.3V
- Current - Peak Pulse (10/1000µs) 48A (8/20µs)
- Power - Peak Pulse 400W
- Power Line Protection No
- Applications Automotive
- Capacitance @ Frequency -
- Operating Temperature -55°C ~ 150°C (TJ)
- Mounting Type Surface Mount
- Package / Case DO-214AC, SMA
- Supplier Device Package SMA (DO-214AC)
- Base Part Number SM4T
- detail 48.3V Clamp 48A (8/20µs) Ipp Tvs Diode Surface Mount SMA (DO-214AC)
