Power Products Catalog دیتاشیت

Power Products Catalog

مشخصات دیتاشیت

نام دیتاشیت Power Products Catalog
حجم فایل 4147.625 کیلوبایت
نوع فایل pdf
تعداد صفحات 40

دانلود دیتاشیت Power Products Catalog

دانلود دیتاشیت

سایر مستندات

APT53F80J 4 pages

مشخصات فنی

  • Manufacturer: Microchip Technology
  • Series: POWER MOS 8™
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 800V
  • Current - Continuous Drain (Id) @ 25°C: 57A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 110mOhm @ 43A, 10V
  • Vgs(th) (Max) @ Id: 5V @ 5mA
  • Gate Charge (Qg) (Max) @ Vgs: 570nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 17550pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 960W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Chassis Mount
  • Supplier Device Package: ISOTOP®
  • Package / Case: SOT-227-4, miniBLOC
  • detail: N-Channel 800V 57A (Tc) 960W (Tc) Chassis Mount ISOTOP®
