دیتاشیت PMN55LN,135

PMN55LN

مشخصات دیتاشیت

نام دیتاشیت PMN55LN
حجم فایل 342.151 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت PMN55LN

PMN55LN Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: TrenchMOS™
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 20V
  • Current - Continuous Drain (Id) @ 25°C: 4.1A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Rds On (Max) @ Id, Vgs: 65mOhm @ 2.5A, 10V
  • Vgs(th) (Max) @ Id: 2V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 13.1nC @ 10V
  • Vgs (Max): ±15V
  • Input Capacitance (Ciss) (Max) @ Vds: 500pF @ 20V
  • FET Feature: -
  • Power Dissipation (Max): 1.75W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 6-TSOP
  • Package / Case: SC-74, SOT-457
  • Base Part Number: PMN5
  • detail: N-Channel 20V 4.1A (Tc) 1.75W (Tc) Surface Mount 6-TSOP
