دیتاشیت 2SA2039-TL-E
مشخصات دیتاشیت
| نام دیتاشیت | 2SA2039/2SC5706 |
|---|---|
| حجم فایل | 428.689 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت 2SA2039/2SC5706 |
2SA2039/2SC5706 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: onsemi 2SA2039-TL-E
- Transistor Type: -
- Collector Current (Ic): -
- Power Dissipation (Pd): -
- Transition Frequency (fT): -
- Collector Cut-Off Current (Icbo): -
- Collector-Emitter Breakdown Voltage (Vceo): -
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): -
- Package: TO-252
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Current - Collector (Ic) (Max): 5A
- Voltage - Collector Emitter Breakdown (Max): 50V
- Vce Saturation (Max) @ Ib, Ic: 430mV @ 100mA, 2A
- Current - Collector Cutoff (Max): 1µA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 200 @ 500mA, 2V
- Power - Max: 800mW
- Frequency - Transition: 360MHz
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: 2-TP-FA
- Base Part Number: 2SA2039
- detail: Bipolar (BJT) Transistor PNP 50V 5A 360MHz 800mW Surface Mount 2-TP-FA
